Customized Vibration Bowl Feeder Small Parts Medical Widget Feeding Machine
1 . Descriptions:
Vibratory bowl feeder is very important in automated production, it uses electromagnetic to generate vibration, and then converts it into mechanical vibration, under the action of vibration, the material is transported along the set track.
There is a magnetic coil under the bowl of the vibratory bowl feeder, usually with 1 to 6 electromagnets. This device that converts electromagnetic vibration into mechanical vibration ensures the smooth running of the material, and with the track design of the plate, the material can be conveyed to the production line correctly in accordance with the specified state and direction.
The use of vibrating bowl feeders for production greatly improves production efficiency and avoids the possibility of manual errors.
2 . Specifications:
| Product name | Vibratory Bowl Feeder |
| Material | Aluminum(AL7075), Stainless Steel(SUS304) or Based on Customers' Requirements |
| Controller | CUH,Sanki,Sinfonia,REO,Afag |
| Voltage | 220V 50HZ/110V 60Hz or Based on Customers' Requirements |
| Power | 300W/500W/1000W/1500W/2000W |
| Color | Green or Based on Customers' Requirement |
| After-sales Service | Spare Parts and Technology Support |
| Warranty | 2 Years |
| Certification | CE, ISO9001, ROHS |
| Lead Time | 3 Working Weeks |
3 . Transfer Needles with A Vibratory Bowl Feeder:
A medical device manufacturer needed to automate the loading of disposable needles, and because the needles are small and sharp, manual operation is prone to errors and lead to danger, so the company approached us to use vibratory bowl feeders to convey the needles.
When conveying medical equipment products should pay close attention to the material of the vibratory bowl feeder, using stainless steel or food-grade plastic to make the vibratory bowl feeder, to prevent contamination of the needle. Sensors and cameras should be installed on the conveying track of the vibratory bowl feeder to monitor the arrangement and conveying of needles in real time, and solve problems in time. The company wanted to reduce the number of manual arrivals, so it added a silo to the vibrating bowl feeder, which can load more needles to ensure that the vibratory bowl feeder continues to run.
The application of vibratory bowl feeder greatly improves the production efficiency and reduces the safety hazard. If your company needs automated production, welcome to contact us, we will provide you with professional services.
4 . More Pictures:
